LM64C21P LCD Screen 8 Inch 640×480 LCD Display Panel
Product Details:
| Model Number: | LM64C21P |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|
|
Detail Information |
|||
| Model: | LM64C21P | Panel Type: | A-Si TFT-LCD, LCM |
|---|---|---|---|
| MOQ: | 1PCS | Application: | Industrial Application |
| Shipment: | DHL , FEDEX, UPS ,TNT, EMS And So On | ||
| Highlight: | 8 inch LCD display panel,640x480 LCD screen,LM64C21P LCD display |
||
Product Description
Sharp LM64C21P Industrial LCD Panel (8.0″)
The LM64C21P is an 8.0-inch industrial LCD panel originally produced by Sharp, featuring a 640 × 480 (VGA) resolution in a color CSTN (passive matrix) format designed for industrial applications such as embedded systems, industrial PCs, and control interfaces.
Display Specifications
| Diagonal Size | 8.0 inches |
| Resolution | 640 × 480 (VGA) with RGB vertical stripe pixel configuration |
| Display Mode | STN, normally black, transmissive |
| Display Colors | Color (passive matrix) |
| Pixel Density | ~99 PPI |
| Active Area | ~163.175 × 122.375 mm |
| Overall Dimensions | ~216 × 152.4 × 8 mm |
| Weight | ~280 g |
Electrical & Interface Specifications
| Signal Interface | Parallel data (8-bit), 31-pin connector |
| Supply Voltage | 5.0 V |
| Backlight | CCFL (Cold Cathode Fluorescent Lamp) without built-in driver |
| Touch Option | Not included (panel alone) |
Operating Conditions
| Operating Temperature | ~0 °C to 40 °C |
| Storage Temperature | ~-25 °C to 60 °C |
This panel's operating temperature range makes it suited for indoor industrial environments where stable display performance is needed, though it's not a wide-temperature automotive grade module.
Typical Applications
The LM64C21P is commonly found in industrial control systems, embedded industrial PCs, measurement instruments, and other legacy equipment that require a reliable 8″ color display with a standard VGA interface and moderate operating conditions.
